WiFi-Smart-Radio with DAB+, Internet radio, CD, USB, Bluetooth and Color TFT-display
Key Features
- 2,8“ (7,1 cm) color TFT-display
- Internet radio via WiFi
- DAB+ / FM-RDS Receiver
- 2.1 Stereo Speakers with Integrated Downfire Subwoofer
- Power Output: 43W (RMS), 2.1 System
- Streaming services: Spotify Connect / Amazon Music / Deezer
- Bluetooth Audio-Streaming (A2DP)
- Clock with Dual-Alarm
- CD and USB connection
- Headphone output (3.5 mm jack)
- Speaker cover: metal front grill
- IR-Remote control included
- App Control via UNDOK App
General Features
| Display Type |
TFT Color Display |
| Display Size |
2,8“ (7,1 cm) |
| Menu Language |
Danish, Dutch, English, Finnish, French, German, Italian, Norwegian, Polish, Portuguese, Spanish, Swedish, Turkish |
| Equalizer |
Yes |
| Equalizer Presets |
9 Presets (Normal / Jazz / Rock / Movie / Classic / Pop / News / My EQ)) |
| Alarm |
Yes, Dual Alarm |
| Sleep Timer |
Yes |
| Remote Control |
Yes, 31-keys |
| Remote Control App |
Yes, (UNDOK app) |
Sources
| Tuner |
Yes, FM and DAB+ |
| CD Player |
Yes |
| USB Player |
Yes |
| Bluetooth® |
Yes |
| Auxiliary |
Yes |
| Internet Radio |
Yes |
| Podcasts |
Yes |
| Spotify Connect |
Yes |
| Amazon Music |
Yes |
| Deezer |
Yes |
Tuner
| FM Tuner |
Yes |
| FM RDS |
Yes |
| FM Tuning Frequency Range |
87.5 ~ 108 MHz |
| DAB+ Tuner |
Yes |
| DAB+ Tuning Frequency Range (Band III) |
174.928 ~ 239.2 MHz |
| Mixed Presets |
40 |
CD Player
| CD DA / CD-R/RW |
Yes |
| Signal to noise ratio |
> 70 dB |
| Dynamic range |
> 60 dB |
| MP3 playback |
Yes |
| Program Playback |
Yes |
| Repeat Playback |
Yes, One / Folder / All |
| Random Playback |
Yes |
USB
| Terminal Type |
USB-A |
| Format |
USB Host (Playback) |
| USB Standard |
1.1 Full Speed |
| File System |
FAT 16 / 32 |
| Maximum Current Supply |
0.5 A |
| MP3 Bitrate |
32 kbps ~ 320 kbps |
| Program Playback |
Yes |
| Repeat Playback |
Yes, One / Folder / All |
| Random Playback |
Yes |
Bluetooth
| Bluetooth® |
Yes |
| Version |
4.2 |
| Class |
1 |
| Frequency band |
2.4 GHz (2.402 GHz – 2.48 GHz) |
| A2DP |
Yes |
| AVRCP |
Yes |
| Maximum service area |
About 10m (Communication range may vary depending on the environmental conditions) |
Wi-Fi
| Wi-Fi |
Yes |
| Wi-Fi IEEE Standard |
802.11 |
| Wi-Fi Protocol |
a / b / g / n |
| Wi-Fi Security Encryption |
WEP, WPA, WPA2 (PSK), WPS |
| Wi-Fi Frequency Range |
2.412 ~ 2.472 GHz |
| Wi-Fi Frequency Range |
5.18 ~ 5.32 GHz |
| Wi-Fi Frequency Range |
5.5 ~ 5.7 GHz |
| Wi-Fi Frequency Range |
5.745 ~ 5.825 GHz |
| Wifi Output Power WiFi |
2.4G – 14.47 dbm |
| Wifi Output Power WiFi |
5G – 14.35 dbm |
| Wifi Output Power WiFi |
5.8G – 3.96 dbm |
Input(s) / Output(s)
| Auxiliary Input |
Yes, 3.5 mm Jack at the backside |
| USB Terminal |
Yes, at the backside |
| Headphone Output |
Yes, 3.5 mm Jack at the backside |
Amplifier
| RMS Output Power |
2 x 4 watt |
| RMS Output Power Subwoofer |
1 x 35 watt |
| Total Output Power |
43 watt |
Speaker(s)
| Type |
Integrated 2.1Speaker System |
| Configuration |
2 x 2,5” (6Ω) Full Range + 1 x 4” (4Ω) Bass Integrated Downfire Subwoofer |
| Grill |
Fixed Metal Grill |
Power
| Stand-by Power Consumption |
0.8 Watt |
| Power Supply |
110-240V AC 50/60Hz |
| DC Output |
21V / 2.1A / 44.1W |
| Operational Temperature Range |
0 °C ~35 °C |
In The Box
| Adapter |
Yes |
| Remote control |
Yes |
| Battery included |
Yes, 2 pieces – AAA type |
| Audio Mini-jack to RCA converter cable |
Yes, 1,5 Meter |
| Multi-Language Instruction Manual |
Yes |
Dimensions & Weight
| Dimensions |
(W) 383 x (H) 125 x (D) 215 mm |
| Weight |
3.63kg |
